Figure 6-51 Installing the cover of the I/O module
Step 4 Use a Phillips screwdriver to tighten the two screws on the I/O module. See (2) in Figure
6-51.
----End
6.7.2 Installing an I/O Module
Step 1 Power off the server as instructed in Powering Off the Server.
Step 2 Take a spare I/O module out of its ESD bag.
Step 3 Insert the I/O module into the slot. See (1) in Figure 6-52.
