Huawei FusionServer G5500 - 2.7 Mainboard Components

Figure 2-15 Hard disk slot numbers of a half-width compute node
No. Description
1 Hard disk slot 0
2 Hard disk slot 2
2.7 Mainboard Components
Figure 2-16 shows mainboard components of the G560.
