Huawei OptiX OSN 3500 - General and Enhanced Subrack Views

6
2
Exterior of the General and Enhanced OptiX OSN 3500 Subracks
Front View
a
Side View
b
Oblique View
c
N1PIU\N1PIUA
The exterior of the enhanced OptiX OSN 3500 subrack (1100 W) is the same as that of the general OptiX
OSN 3500 subrack. The N1PIU power board is used for the general OptiX OSN 3500 subrack, and the
N1PIUA power board is used for the enhanced OptiX OSN 3500 subrack (1100 W).
NOTE
