Meaning of the Label for Optical Fiber Connecting the Cabinet to the ODF
Table A-12 describes the information on the label for the optical fiber connecting the cabinet
to the ODF.
Table A-12 Information on the label for the optical fiber connecting the cabinet to the ODF
Content Meaning Example
MN-B-C-D-R/T MN: Cabinet number A01 indicates the first cabinet in row A.
B: Subrack number The subracks are numbered from bottom to
top. 01 indicates the lowest subrack.
C: Slot number The slots are numbered from left to right
and from top to bottom. 01 indicates slot 5
of the subrack.
D: Optical port number The optical port is numbered from left to
right and from top to bottom. 05 indicates
the fifth optical port.
R: Optical receiving
interface; T: Optical
transmitting interface
-
ODF-MN-B-C-R/
T
MN: ODF row and ODF
column.
M: numbered A to Z from front to back in
each row.
N: numbered 01 to 99 from left to right.
G01: ODF in row G and column 01.
B: Row number of the
terminal
Range: 01-99, such as 01.
C: Column number of the
terminal
Range: 01-99, such as 01.
R: Optical receiving
interface
T: Optical transmitting
interface
-
Example of the Label on the Optical Fiber Connecting the Cabinet to the ODF
Figure A-58 shows the label on the optical fiber connecting the cabinet to the ODF.
Figure A-58 Example of the label on the optical fiber connecting the cabinet to the ODF
TO:
G01 01 01 R
A01
01
05
05
T
ODF
SmartAX MA5612 Multi-service Access Module
Maintenance Guide A Appendix
Issue 01 (2012-07-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
307
