No. Item Expected Result

6 Distances between cable ties Distances between cable ties are the

same, and no burr exists.

7 Operating environment The inside and outside of the cabinet

are free from conductive dust or other

sundries.

8 Cables short circuit Check that cables are open-circuited

using a multimeter or an insulation

resistance tester.

9 Circuit breaker specications AC input circuit breaker specications

of the equipment room ≥ Circuit

breaker specications of the AC PDB ≥

AC input circuit breaker specications

of the UPS

10 Battery voltage range ● 6 kVA/10 kVA: Use a multimeter to

measure the voltage between the

positive and negative battery

terminals. Voltage range: 9.6 V x

Number of batteries to 14.4 V x

Number of batteries. For example,

if 20 batteries are installed, the

voltage between the positive and

negative battery terminals should

range from 192 V (20 x 9.6 V) to

288 V (20 x 14.4 V).

● 15 kVA/20 kVA: Use a multimeter

to measure the voltages of the

positive and negative battery

strings. Voltage range: 9.6 V x

Number of batteries to 14.4 V x

Number of batteries. For example,

if both the positive and negative

battery strings contain 20 batteries,

the voltage of each battery string

should range from 192 V (20 x 9.6

V) to 288 V (20 x 14.4 V).

UPS2000-G-(6 kVA–20 kVA)

User Manual (Lead-Acid Battery) 4 Installation
