Pub. 42004-550A
Elemec3 Console Manual—Version 3.0 Page 72 of 114
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-550A.docx
09/20
Figure 74. Playback Audio Configuration
Add Message
Click ADD MESSAGE… on the PLAYBACK AUDIO CONFIGURATION screen to open the CREATE NEW
MESSAGE screen.
Figure 75. Create New Message
Description—unique description of the message. (This name identifies the message in all areas of the
system.)
