Select Region/Country…—Select the region or country for the E3 system installation to narrow the
TIME ZONE selection list.
Time Zone:—Click the drop-down list and select the time zone for the E3 system installation.
1. Click ADD SCHEDULED EVENT to create a new scheduled event.
The CREATE NEW SCHEDULED EVENT dialog box opens:
Figure 90. Create New Scheduled Event
2. Enter a description for the new scheduled event and click CREATE NEW SCHEDULED EVENT.
The SCHEDULED EVENT BUILDER window opens:
Figure 91. Scheduled Event Builder
Description:—the description entered on the CREATE NEW SCHEDULED EVENT dialog box.
Interval Type:—Use the drop-down list to select: DAY OF WEEK, WEEK OF MONTH, or DAY OF
MONTH.
