Humminbird SOLIX series User Manual

191
Sonar Alarms
SONAR ALARMS
B
efore you start navigating and fishing with your control head, set up sonar alarms. A functioning transducer must be attached to
t
he control head or selected as the transducer source on the network to enable all sonar functions.
Turn on Sonar Alarms
1. Press the HOME key.
2. Select Alarms.
3. Select Alarms > Sonar.
4. Select an alarm and turn it on. Tap the on/off button, or press the ENTER key, to turn it on.
5. Press and hold the slider, or press and hold the ENTER key, to adjust the range setting.
Fish (Shallow)
Turn on Fish (Shallow) to receive an alarm if fish are detected in shallow water. You can also
adjust the shallow water range with the slider.
Fish (Deep)
Turn on Fish (Deep) to receive an alarm if fish are detected in deep water. You can also adjust
the deep water range with the slider.
Shallow Water If the bottom depth is less than the amount you set, the control head will provide an alarm.
Deep Water If the bottom depth is more than the amount you set, the control head will provide an alarm.

Humminbird SOLIX series Specifications

General

Depth-Sonar Standard	Up to 1, 500 feet (varies by model)
Interface	Touchscreen
GPS	Yes
Cartography	Humminbird Basemap
Target Separation	2.5 inches
Networking	Ethernet, NMEA 2000
Memory Card Slot	Yes
Waterproof	IPX7
Operating Frequency	1.2MHz
Dimensions	Varies by model
Weight	Varies by model
Display Size	10.1", 12.1"
Display Resolution	1280 x 800 pixels (varies by model)
Operating Temperature	-15°C to 55°C (5°F to 131°F)
