Humminbird SOLIX series User Manual

225
Images Tool
IMAGES TOOL
T
he Images tool displays the screen snapshots saved to the control head or to the installed SD cards. You can edit, rename, copy,
a
nd delete a screen snapshot. You can also view your saved screen snapshots (JPG files) as a slide show.
Take a Screen Snapshot
Use the screen snapshot feature to take a picture of the on-screen view. The screen snapshot includes the warnings, menus, and
messages that were active when the screen snapshot was taken. If Create Waypoint is turned on, a waypoint will be marked when
you take the screen snapshot. See Screen Snapshot Settings for details.
1. Press and hold the GO TO/Screen Snapshot key.
Open the Images Tool
Open the Images tool to see all the screen snapshots saved to the control head, installed SD cards. You can also view each save
location individually, and the images can be sorted by name, date, or file type.
Open the Images Tool
1. Press the HOME key.
2. Select the Images tool.
Browsing Screen Snapshots in the Images Tool
saved screen
snapshots
images
saved to the
installed
SD cards
images
saved to the
control head

Humminbird SOLIX series Specifications

General

Depth-Sonar Standard	Up to 1, 500 feet (varies by model)
Interface	Touchscreen
GPS	Yes
Cartography	Humminbird Basemap
Target Separation	2.5 inches
Networking	Ethernet, NMEA 2000
Memory Card Slot	Yes
Waterproof	IPX7
Operating Frequency	1.2MHz
Dimensions	Varies by model
Weight	Varies by model
Display Size	10.1", 12.1"
Display Resolution	1280 x 800 pixels (varies by model)
Operating Temperature	-15°C to 55°C (5°F to 131°F)
