Humminbird SOLIX series User Manual

5
TABLE OF CONTENTS
Sonar Overview 184
Sonar Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190
Sonar Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191
2D Sonar Overview 192
Customize the 2D Sonar View . . . . . . . . . . . . . . . . . . . . . . . . . . .193
Open the 2D Sonar Preferences Menu . . . . . . . . . . . . . . . . . . . .193
Change the 2D Sonar View Overlays . . . . . . . . . . . . . . . . . . . . . .199
Adjust 2D Sonar Display Settings . . . . . . . . . . . . . . . . . . . . . . . .200
Side Imaging Overview 205
Customize the Side Imaging View . . . . . . . . . . . . . . . . . . . . . . . .207
Open the Side Imaging Preferences Menu . . . . . . . . . . . . . . . .207
Change the Side Imaging View Overlays . . . . . . . . . . . . . . . . . .209
Adjust Side Imaging Display Settings . . . . . . . . . . . . . . . . . . . . .210
Down Imaging Overview 213
Customize the Down Imaging View . . . . . . . . . . . . . . . . . . . . . . .214
Open the Down Imaging Preferences Menu . . . . . . . . . . . . . . .214
Change the Down Imaging View Overlays . . . . . . . . . . . . . . . . .216
Adjust Down Imaging Display Settings . . . . . . . . . . . . . . . . . . . .217
Use Cursor and Zoom in Sonar Views (2D, SI, DI) 220
Navigation in Sonar Views (2D, SI, DI) 222
Sonar Recording 224
Images Tool 225
Installation Information 231
Set up or Change Transducer Settings (advanced settings) . . .232
Configure Humminbird Radar (Installation and Repair only) . .240
Configure the Control Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . .243
Set up a NMEA 2000 Network . . . . . . . . . . . . . . . . . . . . . . . . . . .247
Set up your Humminbird Network . . . . . . . . . . . . . . . . . . . . . . . .256
Change the Network Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .262
Manage your Control Head 264
Update Software 266
Specifications 270
Statements and Acknowledgements 282
Contact Humminbird 288

Humminbird SOLIX series Specifications

General

Depth-Sonar Standard	Up to 1, 500 feet (varies by model)
Interface	Touchscreen
GPS	Yes
Cartography	Humminbird Basemap
Target Separation	2.5 inches
Networking	Ethernet, NMEA 2000
Memory Card Slot	Yes
Waterproof	IPX7
Operating Frequency	1.2MHz
Dimensions	Varies by model
Weight	Varies by model
Display Size	10.1", 12.1"
Display Resolution	1280 x 800 pixels (varies by model)
Operating Temperature	-15°C to 55°C (5°F to 131°F)
