Master Valve (P/MV) Operation per Station
For selecting a master valve to be on/off for a individual zone, this can be done when
editing the zone in zones and schedules under advanced settings. This option is useful
when one zone is using city water and another is using from another source.
Note: This option is for HPC and HCC controllers only.
Please follow the steps below to change this setting.
1. From the Zones and Schedules page, click on the icon on the zone you would like
to edit.
2. Click on Advanced located on the top blue search section.
3. Select Use Global Master Valve Setting to keep this circuit on or select Disable
Master Valve to turn this circuit off.
Valve - Wire Distance
Below is a chart indicating the maximum wire run between the controller and the Hunter AC
To Next Page
