17
NOTE: A basic programming rule is that whatever
symbol or character is ashing will be the item pro
-
grammed. For instance, if the hour is ashing when set-
ting the time, the hour can be changed or programmed.
For illustration purposes in this manual, ashing char
-
acters are in GRAY type.
The X-Core display shows the time and day when the controller is idle.
The display changes when the dial is rotated to indicate the specic
programming information to enter. When programming, the ashing
portion of the display can be changed by pressing the
or buttons.
To change something that is not ashing, press the
or buttons until
the desired eld is ashing.
Three programs A, B, and C, each with the ability to have four daily
start times, permit plants with dierent watering requirements to be
separated on dierent day schedules.
Setting the Date and Time
1. Turn the dial to the CURRENT TIME/DAY position.
2. The current year will be ashing. Use the
or buttons to change
the year. Aer setting the year, press the
button to proceed to
setting the month.
3. The month and day will be in the display. The month will be ash
-
ing and the icon will be displayed. Use the or buttons to
change the month. Press the
button to proceed to setting the day.
4. The day will be ashing and the
icon will be displayed. Use the
or buttons to change the day. Press the
button to proceed
to setting the time.
5. The time will be displayed. Use the
and buttons to select AM,
PM, or 24 hour. Press the
button to move to hours. Hours will be
ashing. Use the
and buttons to change the hour shown on
the display. Press the
button to move to minute. Minutes will be
ashing. Use the
and buttons to change the minutes shown on
the display. The date, day, and time have now been set.
CURRENT TIME/DAY
PROGRAMMING THE CONTROLLER
