18
Setting the Program Start Time(s)
1. Turn the dial to the START TIMES position.
2. The factory preset is set on program A. If
necessary, you can select program B, or C
by pressing the
button.
3. Use the or button to change the
start time. (The start times advance in
15 minute increments).
4. Press the button to add an additional
start time, or
button for the next
program.
NOTE: One start time will activate all stations sequen-
tially in that program. This eliminates the need to enter
each station’s start time. Multiple start times in a pro
-
gram can be used for separate morning, aernoon, or
evening watering cycles. Start times may be entered in
any order. The X-Core
®
will automatically sort them.
Eliminating a Program Start Time
With the dial set to START TIMES position,
push the
or button until you reach
12:00 AM (Midnight). From here push the
button once to reach the OFF position.
Setting Station Run Times
1. Turn the dial to RUN TIMES position.
2. The display will show the last program
selected (A, B, or C), the station number
selected,
icon, and the station will be
ashing. You can switch to another
program by pressing the button.
3. Use the or button to change the
station run time on the display. You can
set the run times from 0 to 4 hours.
4. Press the button to advance to the
next station.
Setting Days To Water
1. Turn the dial to the WATER DAYS position.
2. The display will show the last program
selected (A, B, or C). You can switch to
another program by pressing the button.
3. The controller will display the seven days
of the week (MO, TU, WE, TH, FR, SA, SU).
Each day will have a
icon or a icon above
the day. The
icon would represent an “On”
water day, while a
icon would represent an
“O” watering day.
WATER DAYS
START TIMES
RUN TIMES
START TIMES
PROGRAMMING THE CONTROLLER
