25
NOTE: If a Stations Runtime is less than or equal to the
Cycle time then no Cycle will be applied.
NOTE: Before 1 hour only minutes are displayed (36, for
example). At 1 hour or above, the display will change to
include the hour digit (1:13 and 4:00, for example).
ADVANCED FEATURES
Cycle and Soak
The Cycle and Soak feature is an enhancement to the existing X-Core
controller. It is designed to aord customers the ability to minimize
runo due to dierent soil and terrain characteristics.
The Cycle and Soak feature allows you to split a station’s runtime into
shorter watering periods. The shorter watering periods will help prevent
run o in situations like slopes or tight soils. It is recommended that the
Cycle time is less than the station’s watering time, and the Soak time
for the water to be absorbed. The total number of cycles is determined
by taking the total programmed station run time and dividing it by the
Cycle time.
Accessing the Cycle and Soak Menu
With the dial in the RUN position, press and holding the
button for
3 seconds; while holding the button rotate the dial to the RUNTIME
dial position, then release the button.
Setting the Cycle Time
1. Initially Station 1 will be displayed. To
access other stations, press the
or
button.
2. Once the desired station is displayed,
use the
or button to increase or
decrease the Cycle time. The user can
set the time from 1 minute to 4 hours
in 1 minute increments or to OFF if no
Cycle is desired.
Cycle Screen With Only Minutes Cycle Screen With Hours Included
Accessing the Soak Menu
Once the desired Cycle times for each station has been programed the
soak time can be accessed by pressing the
button.
The station will remain the same as was previously displayed under the
Cycle time (if station 2 is displayed in the Cycle menu then Station 2 will
be displayed upon pressing the
button, for example).
NOTE: The Soak menu cannot be accessed without a
programmed Cycle time.
