INSTALLATION
16
■
Install the cover with the slot aligned to the socket in the battery wand.
■
Plug the power cable from the shading into an extension cable.
■
Plug the other end of the extension cable into the socket in the battery wand.
NOTE: When power is connected to the motor, a blue LED inside the control button
housing will flash to indicate the shading is ready for operation.
PowerView
®
Gen 3 Shading:
Proceed to“Operate the Shading” on page 21.
Battery Wand Cover
Slot
Battery Wand Cover
Extension
Cable
Power Cable from Shading
To Next Page
