Page 17
(Function not available)
An active humidity sensor can
be directly connected to the
Comfort or the Comfort Plus.
Upon request, HygroMatik will
provide an active sensor with a
control signal of 0-10 V DC.
Sensors with other control sig-
nals can also be used; the con-
trol need only be set to them.
Acceptable Output Signals
from an Active Sensor
(Parameter E3)
0(2) - 5 V DC
0(2) - 10 V DC
0(4) - 20 V DC
0(2) - 10 mA DC
0(4) - 20 mA DC
0-140 Ohm
Active SensorConnector Strip
Connection: Active Sensor,
one-cylinder and double- cylin-
der humidifier; voltage output
Basic
Comfort / Comfort Plus
Proportional Control
with Built-In PI-Controller
