MX3657-01 Rev. D ©2020
112 hysecurity.com | 800-321-9947 StrongArm Programming and Operations
Type Alert/Fault/Error Display Buzzer Chirp Sequence Possible Cause & Suggested Corrective Action
ERROR ERROR 10
SLOWDOWN SWITCH
3 chirps per second once per
minute
VFD only. The operator tripped the fully Open or Close limit before
the Slowdown limit tripped. Check:
• Slowdown limit wiring and adjustment
• Adjustment of the limit ramps to verify that the limit switch
is being tripped. Manually trip the slowdown limit. OPEN
SLOWDOWN or CLOSE SLOWDOWN should appear on the
display which indicates that it is working properly.
FAIL FAIL
PROGRAM DATA ERR
FAIL
3 chirps per second once per
minute
• Try turning off the power to the operator and having the customer
re-seat all of the various connectors and cables.
• Upload the latest software release. If the fail does not go away,
contact Technical Support.
aCCess the eVent loG throuGh the user Menu
NOTE: While you are viewing the event log, the gate operator is in Menu mode and cannot run open or close.
1. To enter the User Menu, press the Menu key twice.
2. Press Next and scroll until “LG 0 (OFF)” appears in the display.
3. Press Select. LG blinks.
4. Press Next to change the number to 1,
LG 1 (ON)
VIEW EVENT LOG
5. Press Select. The most recent event recorded in the log appears.
6. To scroll through the event log, press Next or Prev.
NOTE: Hold down Next or Prev to scroll quickly toward the top or bottom
of the event log.
7. To exit, press Menu. The display resets to LG 0 (OFF).
8. Press Menu again to exit the User Menu and return to Run/Program
mode.
Month / Day Time (HH:MM) Event Type
03/17 15:27 ALE5
Description: ALERT 5: BOTH LIMITS TRIPPED
NOTE: Over 300 events can be recorded before the software begins overwriting the existing log history.
LG 0 (OFF)
VIEW EVENT LOG
LG 1 (ON)
VIEW EVENT LOG
03/17 15:27 ALE5
BOTH LIMITS TRIP
