62 hysecurity.com | 800-321-9947 StrongArm Programming and Operations
The following chart describes the scrolling status displays in the StrongArm models.
Operator Status Display Variables Description
Build Year Indicates whether the gate operator was
manufactured before or after UL 325 -
2016 Safety of Standard changes that
require monitoring of external entrapment
sensors.
All gate operators manufactured in 2016
or later will show Build Year - Post 2016
because it contains software version h4.50.
If you plan to upload 4.50 software (or
later) into your gate operator, you will need
to set the appropriate build year according
to the date of manufacture.
Dual Gate or Sequenced Gate This display only appears when the
operator is used in interlocked or
sequenced gate systems and indicates the
function of the operator. See Bi-Parting
& Dual Gate Systems on page 85 and
Integrating with Security Systems and
HyNet™ Gateway on page 77.
Indicates, in an interlocked or dual gate
setting, whether the operator is set to
Primary or Secondary or Sequenced Gate
Conguration). The setting is assigned in
the Installer Menu.
Operator Type (OT) OT 1 = StrongArm
OT 7 = StrongArm 50VF series
Indicates and identies the operator.
Set Handing (SH) L = Left and R = Right Indicates gate handing.
Usage Class (UC) 1, 2, 3, or 4 Displays the operator’s Usage Class
designation per UL 325 standards.
Input Voltage VDC The number varies depending on the
voltage that the power board is providing.
Input voltage (DC Buss voltage) to the
STC is shown. Helps to determine proper
power connections.
Cycle Count (CC) One cycle equals a full open and close
sequence. Partial cycles are not counted
Displays the number of cycles the gate
operator has incurred. Similar to an
odometer, it resets to zero after 999,999
cycles.
Close Timer (CT) The rst menu item in the User Menu. Displays the number of seconds before the
open gate initiates. NOTE: You can also
access the Installer Menu from this display.
Stop the Status Display Scrolling
To stop the operator status display scroll and focus on one item, press Select. Press Select a second time, to
resume the scrolling display.
Change the Contrast on 7 Segment Displays
NOTE: Since sunlight does not affect readability on the OLED display, changing the display contrast is not available on models
shipped with the 32 character display.
While the operator status displays are scrolling, you can change the contrast by pressing the up or down arrow
keys. The display’s contrast changes accordingly.
Display Power Saving Mode
To conserve energy, the display dims after a period of time if no keypress, run command or fault occurs. When
an event (keypress, run command, or error/alert/fault notication) occurs, the display returns to full brightness.
