64 hysecurity.com | 800-321-9947 StrongArm Programming and Operations
user Menu: taBle 5
User Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
CT 0 (OFF)
CLOSE TIMER
0 = Timer disabled (OFF)
1 second to 99 seconds
Assign how many seconds before open gate initiates
automatic closure. Keep setting at 0 if a hardwired,
push-button control device is being used..
NOTE: CLOSE TIMER display does not appear when
HOLD TO CLOSE is set to 1.
Not applicable (N/A)
HC 0 (OFF)
HOLD TO CLOSE
0 = off
1 = on
Set to 0 to produce a gate closure when a momentary
signal is transmitted.
Set to 1 if a constant hold to close signal, such as a
push button control, is being used. A setting of 1 also
deactivates the automatic close timer and causes its
menu to disappear. The Hold to Close replaces the
Close Timer display as the User Menu entry display.
NOTE: To comply with UL 325 Type D protection,
set HC to 1. Type D UL 325 compliance means no
automatic closing device, such as a timer, loop sensor,
or similar device shall not be employed.
COM
Close
HO (OFF)
HOLD TO OPEN
0 = off
1 = on
Similar to Hold to Close, but congures the Open
inputs for a constant-hold function.
0 = Momentary open signal
1 = Constant hold open push button required
To comply with UL 325 Type D protection, you must
set HO to 1.
COM
Open
AP 0
AC LOSS
0 = UPS FAIL OPEN
1 = UPS FAIL CLOSE
2 = AUTO OPEN
3 = NO CLOSE TIMER
This menu item only appears if the operator is DC
powered. The setting congures how the gate
functions when AC power fails. For more information,
refer to the supplemental documentation. See page
2.
COM
Terminal #21
UPS Terminal strip 24
VDC to control box
power disconnect
switch - and +
RO 0 (OFF)
RADIO OPEN/CLOSE
0 = off
1 = on
A setting of zero, congures radio input for open only.
Setting 1 adds the capability for radio input to close
the gate, but only when it is fully open.
COM
RADIO Open
BF 2 (ON 2 SEC)
WARN BEFORE OPER
0 = off
1 = warning buzzer on
throughout gate travel
2 = warning buzzer on for
2 seconds of gate travel
3 = warning buzzer on
during gate travel
Controls the warn-before-operate buzzer and can be
congured three ways:
Set to 0: Buzzer is disabled. The buzzer will still beep
if alerts, faults, errors, or entrapment occur.
Set to 1: Buzzer beeps for 3 seconds before gate
moves and continues through entire length of travel.
Set to 2: Buzzer beeps for 3s before gate moves and
continues for 2s of travel.
Set to 3: Available on barrier operators only and
UC 4 if sensor inputs set to 1 “NOT USED”. Buzzer
beeps when gate starts to move and continues
throughout gate travel.
Not applicable (N/A)
