MX3657-01 Rev. D ©2020
34 hysecurity.com | 800-321-9947 StrongArm Programming and Operations
NOTE: Distance shown in U.S. Standard “feet.” Metric equivalent shown in parentheses.
StrongArm Wire Size Chart – 208V Three Phase
Horsepower ½ ¾ 1 2 3 5
Amps 2.7 3.1 4.2 6.5 6.7 16
Wire Gauge Distance Distance Distance Distance Distance Distance
12 590 (180m) 510 (155m) 375 (114m) 245 (75m) 235 (72m) 100 (30m)
10 930 (283m) 810 (247m) 600 (183m) 390 (119m) 575 (175m) 160 (49m)
8 1475 (449m) 1285 (392m) 950 (289m) 615 (187m) 595 (181m) 250 (76m)
6 2350 (716m) 2045 (623m) 1510 (460m) 975 (297m) 945 (288m) 400 (122m)
4 3720 (1134m) 3240 (987m) 2390 (728m) 1545 (471m) 1500 (457m) 630 (192m)
StrongArm Wire Size Chart – 230V Three Phase
Horsepower ½ ¾ 1 2 3 5
Amps 2.4 3.0 3.8 6.2 6.4 15.4
Wire Gauge Distance Distance Distance Distance Distance Distance
12 730 (222m) 585 (178m) 460 (140m) 280 (85m) 270 (82m) 115 (35m)
10 1160 (353m) 930 (283m) 730 (222m) 450 (137m) 435 (133m) 180 (55m)
8 1835 (559m) 1470 (448m) 1160 (353m) 710 (216m) 690 (210m) 285 (87m)
6 2925 (891m) 2340 (713m) 1845 (562m) 1130 (344m) 1095 (334m) 455 (139m)
4 4625 (1410m) 3700 (1128m) 2920 (890m) 1790 (546m) 1735 (529m) 720 (219m)
StrongArm Wire Size Chart – 460V Three Phase
Horsepower ½ ¾ 1 2 3 5
Amps 1.2 1.5 1.9 3.1 3.2 7.7
Wire Gauge Distance Distance Distance Distance Distance Distance
12 2915 (888m) 2350 (716m) 1850 (564m) 1130 (344m) 1100 (335m) 455 (139m)
10 4640 (1414m) 3710 (1131m) 2930 (893m) 1800 (549m) 1740 (530m) 725 (221m)
8 7340 (2237m) 5870 (1789m) 4650 (1417m) 2840 (866m) 2750 (838m) 1150 (350m)
6 11700 (3566m) 9350 (2850m) 7400 (2255m) 4550 (1387m) 4400 (1341m) 1800 (549m)
4 18500 (5639m) 14800 (4511m) 11700 (3566m) 7200 (2194m) 7000 (2134m) 2900 (884m)
