Status Indication
LCD Icon
Icon Name Icon Radio Status
Operation
Mode Icon
DM
Direct Mode: Under
this mode, radios
communicate with
each other directly.
RM
Repeater Mode:
Under this mode,
radios communicate
with each other via a
repeater.
RSSI Icon
More bars indicate
better signal strength.
Message
Icon
New message/unread
message
InBox is full.
Scan Icon
The radio is scanning.
Scanning pauses
on a non-priority
channel.
Scanning pauses on
Priority Channel 1.
Scanning pauses on
Priority Channel 2.
Roam Icon The radio is roaming.
Tx Power
Icon
Low Tx power for the
current channel
High Tx power for the
current channel
Battery
Power Icon
More bars indicate
more battery power.
Monitor Icon
The Monitor feature
is active.
Icon Name Icon Radio Status
Speaker
Icon
The speaker is
unmuted.
Emergency
Icon
The Emergency mode
(other than secret
emergency) is active
or an emergency
alarm is received.
VOX Icon
The VOX feature is
active.
Accessory
Icon
An accessory is
connected.
GPS Icon
The GPS feature is
active, and valid GPS
data is received.
The GPS feature is
active, but no valid
GPS data is received.
Scrambler/
Encrypt Icon
The Scrambler/
Encrypt feature is
active.
Missed Call
Icon
You have missed
call(s).
DTMF
Keypad Icon
The DTMF keypad is
enabled.
Work Order
Icon
One or more new
work orders are
received.
LED Indicator
The top LED will help you easily identify the current
radio status.
LED Indication Radio Status
The LED ashes
green
Powering on
The LED glows red Transmitting
The LED glows
green
Receiving
The LED ashes
orange slowly
Scanning
The LED ashes
orange rapidly
Emergency
The LED glows
orange
No voice is being transmitted
or received on the channel
after a call is established.
Within such period, you can
hold the PTT key to talk.
The LED glows
blue and then turns
to ash once every
3s.
The LED glows blue when
the BT is being powered on,
and turns to ash once every
3s when the BT is powered
on without any BT device
connected.
The LED ashes
blue once every 2s.
BT devices are connected.
