6
Stainless Sheet
Side Cover
Right Side
Opposite Motor End
Motor End
Base
Motor Cover
Slider
Left Side
Front Cover
Bearing Housing
Cable
Pulley Cover
Slider Cover
Rear Cover
4.3 Motor Reversing Type RCS2
SA4R, SA5R, SA6R, SA7R, SS7R, SS8R
Cautio
n: The cable directly connected to the actuator is not robot cable even when ordered
with robot cable option. When designing, please be sure not to give repeated
bending loads to this cable. The robot cable is applicable only to the connecting
cables.
