IAI ROBO Cylinder RCS2 Series User Manual

15
7.2.2 Using Side Faces of the Foot Base as Reference Planes
(If Equipped with Optional Foot Bases)
 The side faces of the foot base provide the reference planes for slider travel.
 When precision is required, use these surfaces as the reference planes for mounting.
Type Dimension A
SA4 9.5 mm
SA5 11 mm
SA6 12 mm
Foot base
Reference plane
(side face of the base)
For position
adjustment
