IAI ROBO Cylinder RCS2 Series - Using a Slider Spacer (Optional)

18
2-

3H, depth 5
4-M3, depth 7
7.4.2 Using a Slider Spacer (Optional)
(Optional for SA4 Type)
For the SA4 type, a slider spacer is available as an option.
The figure below shows the positions of load-mounting holes in actuators with a slider spacer.
