2. Open the relevant drawer by using the instructions in "Opening a Drawer".
3. Locate the drive to be replaced, either by using the drive plan in the previous figure or by looking for
the amber LED on the drive that indicates a fault.
4. Push the drive carrier latch in the direction that is shown in the following figure to unlock the drive.
5. Pull the drive upward and out of the drawer.
Important: If you are not going to replace the drive immediately, close the drawer (see "Closing a
Drawer") so that correct airflow and cooling are maintained in the enclosure.
Inserting a DDIC
Important: Failed drives must be replaced with approved drives. Contact your storage vendor for details.
1. If the relevant drawer is not already open, open it using the instructions in "Opening a Drawer".
2. Lower the DDIC into the slot, with the drive capacity label facing towards you, as shown in the
following figure.
3. Push the DDIC downwards and hold it down while sliding the drive carrier plate in the direction
shown in the previous figure. This action locks the drive in place.
Figure 37. Removing a DDIC
Figure 38. Installing a DDIC
44 Slicestor
®
2584 Appliance Manual
