Table 3. Storage capacities and feature codes of NVMe-attached drives (continued)
Feature code Description FRU part number
AK0L 15.36 TB 2.5 in. PCIe Gen 4
NVMe-attached drive
03JN946
AK0M 30.72 TB 2.5 in. PCIe Gen 4
NVMe-attached drive
03JN947
• 24 or 48 drives per enclosure congurations are available.
• Onboard ports per canister:
– Two RJ45 of 10 GbE for management
– One RJ45 of 1 GbE for BMC inter-canister communication
– One mini HDMI port for console display
– One USB 3.0 type A port for crash-cart keyboard
– One USB Mini-C for service
– Various I/Os depending on the add-in cards
• Up to eight Gen 5 x16 PCIe slots per canister. These slots support the following adapter options:
– PN: 01LL984 - CX-7 VPI, dual port, 200 Gb.
– PN: 01LL983 - CX-7 InniBand, single port, 400 Gb.
The ports and LEDs details of IBM Storage Scale System 6000 are shown in the following gure.
Chapter 2. Technical overview
13
