161
Adjustment Procedures
1. Timing Belt Shield
2. Motor Mount Bolt (2)
3. Paper Feed Drive Motor
4. Splined Shaft
5. Paper Feed T
iming Belt
2
1
3
2
4
Direction of Force
5
Figure 21. Paper Feed Timing Belt Adjustment
