Wire Data312
Cable Assembly, Operator Panel
DescriptionPart No.
14H5300
IMPORTANT:
If you replace the control
panel cable, you must install
two ferrite shielding beads.
See Appendix I.
PIN 1
PIN 1
PIN 8
PIN 8
(Gray)
(Brown)
(Gray)
(Brown)
