186
Adjustment Procedures
Message
Required
Action
Explanation
ERROR: PROGRAM
NOT COMPATIBLE
The printer is not compatible with the
downloaded program. User tried to
load CMX-compatible diskette in
CBO-controlled printer, or vice versa.
Use the correct
emulation software
option(s) for this
model. If the printer
is an IBM
6404–B01, the
controller is a CBO
board. If the printer
is an IBM 6400, the
controller is a CMX
board.
ERROR: PROGRAM
NOT VALID
The printer does not see a program
in flash memory.
There is no program
in printer memory.
Go to step 2.
ERROR: SECURITY PAL NOT DETECTED
The security PAL is not present or
has failed.
Check the security
PAL at location U54
on the CMX
controller. If the PAL
is absent, install the
correct PAL. If
security P
AL is
present, replace the
CMX controller
board.
ERROR: SHORT AT
ADDRESS XXXX
Hardware failure in DRAM or CMX
controller circuitry.
Replace DRAM. If
message occurs
with new DRAM,
replace CMX
controller board.
ERROR: WRITING
TO FLASH
Hardware or software fault in flash
memory.
Download the
program again:
Power off the printer
and start over at
step 13. If the
message occurs
again, replace the
flash memory.
ERROR: WRONG
CHECKSUM
The printer received the complete
program but the checksum did not
match. The data were corrupted
during download.
Download the
program again:
Power off the printer
and start over at
step 13.
LOADING PROGRAM
FROM PORT XX%
The new program is loading into
printer RAM. XX indicates how much
of the program has loaded.
None
