Replacement Procedures and Illustrated Parts List
1
2
3
4
5
6
7
8
9
10
11
12
Hammer Bank
Cover Assembly
Early Models
Later Models
Hammer Bank
Cover
Screw (12)
Screw (6)
Ribbon Mask
Clamp Plate (3)
Hammer Bank Cover
(Thick Plate)
Ribbon Mask
(Thin Plate)
Hammer Bank Cover Torque Sequence
123546
Ribbon Mask Torque Sequence
Figure 31. Hammer Bank Cover Assembly / Ribbon Mask
