321Wire Data
Cable Assembly, Twinax Auto–Termination
DescriptionPart No.
38F8254
White
Gray
Shield
14
7
5
Jack
Jack
15 position D–sub receptacle
connector with EMI/RFI shield.
12
34
Resistance Chart
Pin Pin Ohms
1
3
1, 2, 3, 4
5
14
7
2
4
Shield
Shield
1, 4
2, 3
110
110
55
0
0
0
