IBM 6400 Series Maintenance Manual

401Power Stacker
Item
No.
Part No.
(Order No.)
Description Notes
5 Ref Flanged Bearing Part of item 36
6 24H8966 Paper Deflector
7 Ref Clip-On Bearing Part of item 36
8 Ref Screw, Torx, 6–32x.25 Part of item 36
9 Ref Screw, Shoulder, 10–32 Part of item 36
9A Ref Screw, Shoulder, 8–32 Part of item 36
10 24H8968 Timing Belt
11 24H8996 Shaft, Lift
12 24H9002 Pulley, Timing Belt
13 24H9001 Pulley, Motor
14 57G1521 Clip, Grounding
15 24H8969 Motor
20 24H8970 Constant Force Spring
25 24H8971 Chain Mount chains outboard of
shafts
30 Ref Nylon Plug Part of item 36
35 24H8973 Cable
36 24H9004 Stacker Hardware Kit Kit not illustrated
Other Parts and Assemblies:
24H8974 Control Panel Assembly See Figure 71, page 390.
Ref Rail Cable, Power Stacker See page 327.
24H8975 Power Cable, Power Stacker See page 326.
24H8976 Logic Cable, Power Stacker See page 325.
Ref Frame Cable, Power Stacker See page 324.
24H8962 Rear Door, Extended, Power Stacker Not Illustrated
24H8963 RE Ship Kit, Printer w/Power Stacker Not Illustrated
