IBM 9080-M9S

Table 2. Cabling a Two Node Conguration. Each connection that is shown in the diagram
represents a pair of SMP cables. (continued)
Cable Cable type and length From To
6D 1005 mm (3.3
ft)
ND1-P1-T8 ND2-P1-T8
5A 1005 mm (3.3
ft)
ND1-P1-T9 ND2-P1-T9
5B 1005 mm (3.3
ft)
ND1-P1-T10 ND2-P1-T10
6A 1225 mm (4.01
ft)
ND1-P1-T15 ND2-P1-T15
6B 1225 mm (4.01
ft)
ND1-P1-T16 ND2-P1-T16
6W 1225 mm (4.01
ft)
ND1-P1-T17 ND2-P1-T17
6X 1225 mm (4.01
ft)
ND1-P1-T18 ND2-P1-T18
5W 1005 mm (3.3
ft)
ND1-P1-T23 ND2-P1-T23
5X 1005 mm (3.3
ft)
ND1-P1-T24 ND2-P1-T24
6Y 1005 mm (3.3
ft)
ND1-P1-T25 ND2-P1-T25
6Z 1005 mm (3.3
ft)
ND1-P1-T26 ND2-P1-T26
5Y 880 mm (2.9
ft)
ND1-P1-T31 ND2-P1-T31
5Z 880 mm (2.9
ft)
ND1-P1-T32 ND2-P1-T32
• If you have a three node system conguration, use Figure 28 on page 31 and Table 3 on page 31
to determine the point-to-point cabling for SMP cables.
