IBM 9080-M9S

Table 4. Cabling a Four Node Conguration (continued)
Cable Cable type and length From To
2X 1225 mm (4.01
ft)
ND4-P1-T24 ND2-P1-T22
1Y 1425 mm (4.7
ft)
ND4-P1-T25 ND1-P1-T29
1Z 1425 mm (4.7
ft)
ND4-P1-T26 ND1-P1-T30
4Y 880 mm (2.9
ft)
ND4-P1-T29 ND3-P1-T29
4Z 880 mm (2.9
ft)
ND4-P1-T30 ND3-P1-T30
2Y 1225 mm (4.01
ft)
ND4-P1-T31 ND2-P1-T29
2Z 1225 mm (4.01
ft)
ND4-P1-T32 ND2-P1-T30
Cables originating on ND3
5C 880 mm (2.9
ft)
ND3-P1-T1 ND2-P1-T1
5D 880 mm (2.9
ft)
ND3-P1-T2 ND2-P1-T2
3C 1225 mm (4.01
ft)
ND3-P1-T7 ND1-P1-T1
3D 1225 mm (4.01
ft)
ND3-P1-T8 ND1-P1-T2
5A 1005 mm (3.3
ft)
ND3-P1-T9 ND2-P1-T9
5B 1005 mm (3.3
ft)
ND3-P1-T10 ND2-P1-T10
3A 1225 mm (4.01
ft)
ND3-P1-T15 ND1-P1-T9
3B 1225 mm (4.01
ft)
ND3-P1-T16 ND1-P1-T10
3W 1225 mm (4.01
ft)
ND3-P1-T17 ND1-P1-T23
36 Power Systems: Removing and replacing parts in the 9080-M9S system
