Chapter 3. IBM System x3850 X5 and x3950 X5 77
Standard models contain two or more memory cards. You can configure additional cards, as
listed in Table 3-10.
Table 3-10 IBM System x3850 X5 and x3950 X5 memory card
The memory cards are installed in the server, as shown in Figure 3-17. Each processor is
electrically connected to two memory cards as shown (for example, processor 1 is connected
to memory cards 1 and 2).
Figure 3-17 Memory card and processor enumeration
Part number Feature code Description
46M0071 5102 IBM x3850 X5 and x3950 X5 Memory Expansion Card
Memory cards 1 - 8
Processors 1 - 4
