94 IBM Midrange System Storage Hardware Guide
3.6.2 DS5300 product comparison
Figure 3-70 compares the DS5100 and DS5300. There is no difference between these
models except for the internal front side bus speed. In earlier versions of code, there were
restrictions on cache upgrade and number host channels, which no longer apply with CFW
V7.60.
The DS5100 can be upgraded to the DS5300 by using the Performance Upgrade premium
feature.
Figure 3-70 DS5100 / DS5300 comparison chart
Full clock speed
Reduced clock speed through
internal code
Internal FontsideBus Speed
4 Gbps FC, 8 Gbps FC, 1 Gbps iSCSIHost channel topologys
Dual-controller system
(unless noted)
DS5100 DS5300
Number of host channels Two (iSCSIonly), Eight, or Sixteen
Redundant drive channels Sixteen 4 Gbps
Max drives 448 FC/SATA
Processor Intel Xeon 2.8 GHz
Processor memory (per controller) 2 GB
XOR technology Dedicated ZIP ASIC
Internal controller bandwidth
(per controller)
4 GB/s
Data cache (min/max) 8 / 16 /32 / 64 GB
Cache Hold-up Permanent
Cache Mirroring Two dedicated busses
Cache bandwidth (single controller) 17 GB/s
Full clock speed
Reduced clock speed through
internal code
Internal FontsideBus Speed
4 Gbps FC, 8 Gbps FC, 1 Gbps iSCSIHost channel topologys
Dual-controller system
(unless noted)
DS5100 DS5300
Number of host channels Two (iSCSIonly), Eight, or Sixteen
Redundant drive channels Sixteen 4 Gbps
Max drives 448 FC/SATA
Processor Intel Xeon 2.8 GHz
Processor memory (per controller) 2 GB
XOR technology Dedicated ZIP ASIC
Internal controller bandwidth
(per controller)
4 GB/s
Data cache (min/max) 8 / 16 /32 / 64 GB
Cache Hold-up Permanent
Cache Mirroring Two dedicated busses
Cache bandwidth (single controller) 17 GB/s
