262 IBM Midrange System Storage Hardware Guide
With this relationship, the correct keys, and authentication, the FDE drive will encrypt data
written and decrypt data read from it. But if the disk is removed and data on the disk is
attempted to be read, as shown in Figure 5-2, the user will not have the appropriate
authorizations, as data cannot be read from or written to the drive without authenticating with
the DS5000 Disk Encryption Manager, which will unlock the drive.
Figure 5-2 Unauthorized access to the drive results in the data remaining encrypted
5.2 Disk Security components
There are a number of new components to this new feature that are detailed in this section.
All of these features are managed by the Storage Manager (V10.6.x and higher).
5.2.1 DS5000 Disk Encryption Manager
The Disk Encryption Manager on the DS5000 system maintains and controls the key linkage
and communications with FDE drives. It is included with the firmware (V7.60) and Storage
Manager (V10.6). It:
Provides all the management tools necessary to quickly and simply enable and secure
FDE drives.
Establishes and manages a single authorization scheme for all the FDE drives in a
DS5000 storage subsystem.
– Places FDE drives in a secured state.
– Defines secure arrays.
– Supports the decommissioning or re-purposing of drives with Instant Secure Erase.
IBM DS5000 Disk Encryption
Manager
Self-encrypting Drive
Reading from the Drive
Decryption Process
Data Flow
Authorization Flow
Data on Drive
Data
Encryption
Key
Data cannot be read if
authorization fails
%$#@βδελιφφυιλσκδ%
$#@j&&6544IY899#@&$
