Chapter 3. IBM System Storage DS4000 and DS5000 hardware 49
Figure 3-24 iSCSI faceplate design
Figure 3-25 shows details about the controller LED and its status.
Figure 3-25 DS5000 storage subsystem RAID controller rear LEDs
100/1000
100/1000
Link activity
Link speed (on=1Gbps) Link speed (on=1Gbps, off=100Mbit)
Link activity
Ch 1 Ch 1
Ch 1Ch 1
iSCSI
