This symbol is marked on the frame of the rack.
The PROTECTIVE EARTHING CONDUCTORS should be terminated at that point. A
recognized or certified closed loop connector (ring terminal) should be used and secured
to the frame with a lock washer using a bolt or stud. The connector should be properly
sized to be suitable for the bolt or stud, the locking washer, the rating for the
conducting wire used, and the considered rating of the breaker. The intent is to ensure
the frame is electrically bonded to the PROTECTIVE EARTHING CONDUCTORS. The
hole that the bolt or stud goes into where the terminal conductor and the lock washer
contact should be free of any non-conductive material to allow for metal to metal
contact. All PROTECTIVE EARTHING CONDUCTORS should terminate at this main
protective earthing terminal or at points marked with . (R010)
CAUTION:
The weight of this part or unit is more than 55 kg (121.2 lb). It takes specially
trained persons, a lifting device, or both to safely lift this part or unit. (C011)
CAUTION:
To avoid personal injury, before lifting this unit, remove all appropriate
subassemblies per instructions to reduce the system weight. (C012)
33.6-46.3 kg (74-102 lbs) 46.3-61.7 kg (102-136 lbs)
61.7-100 kg (136-220 lbs)
>
_
svc01053
Chapter 4. Installing an optional 5U SAS expansion enclosure 43
