Components on the rear of the enclosure
Figure 43 shows the components on the rear of the 2145-92F expansion enclosure.
Four fan modules and two expansion enclosures are accessible from the back of the
enclosure.
▌1▐ Power cable connector for PSU 2
▌2▐ Power cable retention clamps
x4
svc01042
Figure 42. Front fascia of the 2145-92F expansion enclosure
svc01010
8
77
8
1
2
4
5
3
6
9
Figure 43. Features on the rear of the 2145-92F expansion enclosure
Chapter 4. Installing an optional 5U SAS expansion enclosure 51
