019 (continued)
– Select test 5.
DID YOU RECEIVE A 17XX ERROR CODE?
Yes No
020
Go to Step 049 on page 2-88.
021
Go to Step 018 on page 2-82.
022
(From step 018)
Error codes: 1701, 1702, 1704, 1710, 1714, 1720, 1780, 1781, or 1782.
– Check that all electrical connections are secure by disconnecting and then
reconnecting them.
– Repeat the operation or diagnostic test that failed.
DID THE SYMPTOM REMAIN?
Yes No
023
Go to Step 054 on page 2-89.
024
(From MAP 2400 step 050 on page 2-106)
(From MAP 2400 step 103 on page 2-116)
IS THERE A SECOND HARD DISK DRIVE INSTALLED?
Yes No
025
Go to Step 063 on page 2-91.
026
(Step 026 continues)
Diagnostic Information 2-83
