IBM System x3650 M3 4255 Service Guide

Table 12. View 1 CRUs and FRUs, Types 4255, 7945, and 7949
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
1 Cover (all models) 59Y3790
2 PCI Express riser-card assembly (x 8) 69Y4324
2 PCI Express riser-card assembly (x 8) (for Emulex 10
GbE adapter, 49Y4202)
59Y3818
2 PCI Express riser-card assembly (x 16) 69Y4325
3 PCI-X riser-card assembly 69Y4326
4 Heat sink, 95 watt 49Y4820
4 Heat sink, 130 watt 69Y1207
5 Microprocessor - Quad-Core Intel Xeon X5570 2.93 GHz
(8 MB cache) 95 W
46D1262
5 Microprocessor - Quad-Core Intel Xeon X5560 2.80 GHz
(8 MB cache) 95 W
46D1263
5 Microprocessor - Quad-Core Intel Xeon X5550 2.66 GHz
(8 MB cache) 95 W
46D1264
5 Microprocessor - Quad-Core Intel Xeon E5540 2.53 GHz
(8 MB cache) 80 W
46D1265
5 Microprocessor - Quad-Core Intel Xeon E5530 2.40 GHz
(8 MB cache) 80 W
46D1266
5 Microprocessor - Quad-Core Intel Xeon E5520 2.26 GHz
(8 MB cache) 80 W
46D1267
5 Microprocessor - Quad-Core Intel Xeon E5506 2.13 GHz
(4 MB cache) 80 W (model A2x)
46D1270
5 Microprocessor - Quad-Core Intel Xeon E5504 2.00 GHz
(4 MB cache) 80 W
46D1271
5 Microprocessor - Hex-Core Intel Xeon X5670 2.93 GHz
(12 MB cache) 95 W (model M2x)
49Y7038
5 Microprocessor - Hex-Core Intel Xeon X5660 2.80 GHz
(12 MB cache) 95 W (models L2x and L4x)
49Y7039
5 Microprocessor - Hex-Core Intel Xeon X5650 2.66 GHz
(12 MB cache) 95 W (models J2x, JSx, and D4x)
49Y7040
5 Microprocessor - Quad-Core Intel Xeon X5667 3.06 GHz
(12 MB cache) 95 W
49Y7050
5 Microprocessor - Quad-Core Intel Xeon E5640 2.66 GHz
(12 MB cache) 80 W (model G2x)
49Y7051
5 Microprocessor - Quad-Core Intel Xeon E5630 2.53 GHz
(12 MB cache) 80 W (model F2x)
49Y7052
5 Microprocessor - Quad-Core Intel Xeon E5620 2.40 GHz
(12 MB cache) 80 W (models D2x and D4x)
49Y7053
5 Microprocessor - Hex-Core Intel Xeon L5640 2.26 GHz
(12 MB cache) 60 W (models H2x and H4x)
49Y7054
5 Microprocessor - Quad-Core Intel Xeon L5630 2.13 GHz
(12 MB cache) 40 W (model C2x)
59Y3691
5 Microprocessor - Quad-Core Intel Xeon E5503 2.00 GHz
(4 MB cache) 80 W
69Y0781
Chapter 4. Parts listing, Types 4255, 7945, and 7949 server 159

IBM System x3650 M3 4255 Specifications

General

Form Factor	2U Rack
Chipset	Intel 5520
Max Processors	2
Processor	Intel Xeon 5600 series
Memory	Up to 192GB DDR3
Network Interface	Dual-port Gigabit Ethernet
Hard Drive Bays	Up to 16 x 2.5" or 6 x 3.5"
RAID Support	RAID 0, 1, 10
Memory Slots	18 DIMM slots
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
