PCI riser-card option connectors
The following illustration shows the connectors on the PCI riser card for
user-installable PCI adapters.
Note: For clarity, in the following illustration the PCI riser-card assembly is inverted.
PCI adapter
connectors
Power-backplane-board connectors
The following illustration shows the internal connectors on the power-backplane
board.
System-board
connector
Hard disk drive
power connector
Fan 10 connector
Fan 7 connector
10 IBM System x3650 Type 7979 and 1914: Problem Determination and Service Guide
