Installing the riser-card assembly

To install the riser-card assembly, complete the following steps.

Access holes

Release tabs

Guide

1. Reinstall any adapters and reconnect any cables you might have removed in

other procedures.

2. Carefully align the riser-card assembly with the release tab posts, the guides on

the rear of the server, and the riser-card connector on the system board; then,

press down on the assembly. Make sure that the riser-card assembly is fully

seated in the riser-card connector on the system board.

3. Install the cover (see “Installing the cover” on page 91).

4. Slide the server into the rack.

5. Reconnect the external cables; then, reconnect the power cords and turn on the

peripheral devices and the server.

Removing an adapter

This topic describes removing an adapter from a PCI slot. To remove a Remote

Supervisor Adapter II SlimLine, go to “Removing a Remote Supervisor Adapter II

SlimLine” on page 101. To remove the ServeRAID SAS controller, go to “Removing

the ServeRAID SAS controller” on page 102.

98 IBM System x3650 Type 7979 and 1914: Problem Determination and Service Guide
