System-board external connectors
The following illustration shows the external input/output connectors on the system
board.
USB 1
USB 2
Ethernet 2 / USB 3
Ethernet 1 / USB 4
Video
Serial
Systems-management Ethernet
SAS
12 IBM System x3650 Type 7979 and 1914: Problem Determination and Service Guide
