d. Slide the rear flange of the heat sink into the opening in the retainer
bracket.
e. Press down firmly on the front of the heat sink until it is seated securely.
f. Rotate the heat-sink release lever to the closed position and hook it
underneath the lock tab.
10. Install the microprocessor air baffle (see “Installing the microprocessor 2 air
baffle” on page 49).
11. Install PCI riser-card assembly 2 (see “Installing a PCI riser-card assembly” on
page 47).
Results
If you have other devices to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 154.
Thermal grease
The thermal grease must be replaced whenever the heat sink has been removed
from the top of the microprocessor and is going to be reused or when debris is
found in the grease.
About this task
To replace damaged or contaminated thermal grease on the microprocessor and
heat exchanger, complete the following steps:
Procedure
1. Place the heat-sink assembly on a clean work surface.
2. Remove the cleaning pad from its package and unfold it completely.
3. Use the cleaning pad to wipe the thermal grease from the bottom of the heat
exchanger.
Note: Make sure that all of the thermal grease is removed.
4. Use a clean area of the cleaning pad to wipe the thermal grease from the
microprocessor; then, dispose of the cleaning pad after all of the thermal grease
is removed.
Figure 118. Heat sink alignment
114 System x3650 M3 Types 4255, 7945, and 7949: Installation and User’s Guide
