Results
Attention: For proper cooling and airflow, replace all air baffles before you turn
on the server. Operating the server with any air baffle removed might damage
server components.
Installing the full-length-adapter bracket
Use this information to install the full-length-adapter bracket.
About this task
If you are installing a full-length adapter in the upper riser-card PCI slot, you must
first install the full-length-adapter bracket in the end of the riser-card assembly.
To install the full-length-adapter bracket, complete the following steps:
Procedure
1. Orient the riser-card assembly as shown.
2. Remove the full-length-adapter bracket from the storage location.
a. Press the bracket tab 3 and slide the bracket toward the end of the
riser-card assembly.
b. Push the bracket out of the storage location on the riser-card assembly.
3. Align the bracket with the end of the riser-card assembly as shown.
4. Place the two hooks 1 in the two openings 2 in the end of the riser-card
assembly.
5. Press the bracket tab 3 and slide the bracket to the right until it clicks into
place.
6. Return to the adapter-installation instructions.
Storing the full-length-adapter bracket
Use this information to store the full-length-adapter bracket.
About this task
If you are removing a full-length adapter in the upper riser-card PCI slot and will
replace it with a shorter adapter or no adapter, you must remove the
full-length-adapter bracket from the end of the riser-card assembly and return the
bracket to its storage location.
Figure 37. Full-length-adapter bracket installationFull-length-adapter bracket installation
52 System x3650 M3 Types 4255, 7945, and 7949: Installation and User’s Guide
