You can purchase an optional kit to install the tape drive.
You can purchase an optional kit to install the eight additional SAS hard disk drive
bays.
SAS hard disk
drive bays
01234567
8 9 10 1112 131415
The SAS ID for each bay is printed on the server front, above each bay.
If firmware and documentation updates are available, you can download them
from the IBM Web site. The server might have features that are not described in
the documentation that comes with the server, and the documentation might be
updated occasionally to include information about those features, or technical
updates might be available to provide additional information that is not included
in the server documentation. To check for updates, complete the following steps.
Note: Changes are made periodically to the IBM Web site. Procedures for locating
firmware and documentation might vary slightly from what is described in this
document.
1. Go to http://www.ibm.com/systems/support/.
2. Under Product support, click System x.
3. Under Popular links, click Software and device drivers for firmware updates,
or click Publications lookup for documentation updates.
Record information about the server in the following table.
Figure 1. SAS hard disk drive bays front view
SAS hard disk
drive bays
01234567
Figure 2. Optional SAS hard disk drive bays front view
Figure 3. SAS ID for each bay
2 System x3650 M3 Types 4255, 7945, and 7949: Installation and User’s Guide
