4. Remove the PCI riser-card assembly that contains the adapter (see “Removing a
PCI riser-card assembly” on page 46).
5. Disconnect any cables from the adapter (make note of the cable routing, in case
you reinstall the adapter later).
6. Carefully grasp the adapter by its top edge or upper corners, and pull the
adapter from the PCI expansion slot.
Results
If you have other devices to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 154.
PCI riser-card
assembly 2
PCI riser-card
assembly 1
Figure 45. PCI riser-card assembly removal
Chapter 2. Installing optional devices 59
