3 SETUP AND BUTTON FUNCTIONALITY
3.1 User Functions (No Access Code required)
ACCEPT Acts only on the internal sounder. It acknowledges all current Alarm states. All other warning mechanisms
continue unchanged. The sounder operation changes from ‘continuous’ to ‘1 second ON: 15 seconds OFF’. New
Alarm events cause the sounder to revert to continuous operation.
TEST Successive presses of the TEST button show first the Date; then Time; then LED TEST (All LED segments
illuminated); then back to normal display.
3.2 Main Menu & Access Code Entry
Access to some Modes in the Main Menu requires the user to enter an Access Code. There are three levels of access, ‘Operator’, ‘Level 1’,
and ‘Level 2’. Access Code Levels are downwards applicable: (e.g. if a User enters the Level 2 Code, they have access at all Levels). The
Operator Code is itself changeable as a parameter from within the Configuration Mode, which requires Level 1 Access. The default
Operator Code is ‘0’. The Level 1 code is ‘260’, the Level 2 code is ‘693’.
To enter one of these Main Menu Modes use the following.
Action Resulting Display Note
1 Press MAIN MENU OPERATOR
2 Use Parameter UP & DOWN buttons to reach required Item <Item on List>
3 Press ENTER CODE 0 If code required
4 Use Value UP & DOWN buttons to Enter Code *** If code required
5 Press ENTER According to Mode
Note on entering an Access Code:
The UP and DOWN buttons are used to enter a 3-digit number. To make the process faster, these buttons, if held down, first act on the
units, then the tens, then the hundreds. If the button is released, the flashing digit (units, tens or hundreds) is the one that will change
with further use of the UP and DOWN buttons. When the hundreds digit is correct, wait about 5 seconds for the flashing digit to change to
the tens, then set the tens to the required value. Repeat for the units.
Code Entry may be aborted by pressing the MAIN MENU button.
Note on entering settings with software:
All of the following settings can be entered using the e-series monitor software and a PC. This can cut down the time taken to enter certain
values and parameters.
To obtain this software contact ICAM or visit the website: www.firetracer.com
